- NO.: SE-VGA8001KVM
- Standards: CE,FCC
- Brand: No Brand
- Views:
uncompressed VGA+KVM fiber transceiver
Our uncompressed VGA+ KVM fiber transceiver used to transmit VGA + KVM+ Audio signal upto 10KM via single fiber cable Max resolution is up to 1080p60Hz
- Digital and uncompressed high resolution image fiber transmission upto 5-20KM
- Compliance to standard VGA protocol
- Support VGA loop-back , Analog audio input/output
- Auto-learning and set different resolution mode
- Max resolution is 1920x1200 @60hz (1KM)
- Support UBM KVM function to remote keyboard control
- Plug and play design to easy install
|
|
VGA +KVM fiber transceiver |
| Input /output Interface | TX --- 1X VGA In, 1X VGA loopback , 1 Audio in , USB2.0/PS2 Rx ---1X VGA Out, USB, Audio Out |
| Digital bit | 24bit |
| Bandwidth | 1.65G HZ (-3db) |
| Rate | 240M Hz~-1.6G Hz |
| Format | VGA,SVGA，XGA，WXGA。 |
| Resolution | 800x600 @60/75hz 1024x768@ 60/75hz 10280x720@60/75hz 1280x800@60/75hz 1280x1024@60/75hz 1600x1200@60/75hz 1920x1200@60/75hz |
| Audio | 3.5mm phone jack |
| Audio format | 44.1k ,48k ,96k,176k,192k |
| KVM interface | PS2 / USB2.0 |
| Fiber optical | |
| Interface | LC |
| Transmitted power | -9.5~-3dBm |
| Receiver Sensitivity | -23dBm |
| Optical Type | Single Mode, Single fiber Wavelength : 1310/1550nm |
| Distance | 5-20 KM (Default 5KM _ |
| Power Supply | DC5V, 1A |
| Working temperature | -5 – 70 |
| Relative Humidity | 20~90% RH (no condensation) |
| Dimension | 300(L)×152(W)×100(H ) |
| Weight | 1.8kg |
